Specifications:
Type: Starter Motor
Quantity: 1
Warranty: 1 Year
Reference OE/OEM Number: Suitable for S06-023, S06-023 (1), S06-023 (3)
Voltage: 12 V
Number of Teeth: 9
Overall Length (mm): 230
Mounting Hole (mm): 11
Mt Holes Centre (mm): 105
Flange Diameter (mm): 82
Nose Cone Length (mm): 32
Field Housing Diameter (mm): 76
Power Rating: 2 kW
Kilowatts: 2.0
Rotation: CW
Pinon Diameter (mm): 34
Pinion At Rest: 26
Features:
High power rating of 2 kW for reliable performance
9 teeth configuration for consistent and efficient starting
CW (Clockwise) rotation for compatibility with various engine setups
Premium build designed for long-lasting use in demanding environments
Easy installation with standard mounting holes and dimensions
Compatible With:
Suitable for KUBOTA Tractors:
L295DT (1979–82) - Engine: Diesel D1301A
L2850F (1985–90) - Engine: Diesel V170DIA
L2850DT (1985–90) - Engine: Diesel V170DIA
L2601 (1977–78) - Engine: Diesel V1500
L2250DT (1985–90) - Engine: Diesel D130DI
L1802 (1980–92) - Engine: Diesel D1100, D1101, D1102
KH14 - Engine: Diesel D7203
L3250F (1989–90) - Engine: Diesel V1902DIA
L2850GST (1985–90) - Engine: Diesel V170DIA
L2250F (1985–90) - Engine: Diesel D130DI
L2202, L2402 (1984–92) - Engine: Diesel D1402, D1402L
L1-20 (1984–92) - Engine: Diesel V1501
Ride-On Mower 5FDL10 (1986–89) - Engine: Petrol V1502
Suitable for KUBOTA Excavators:
KX151 - Engine: Diesel V1902BH
KH90 - Engine: Diesel V1702
KH28 - Engine: Diesel S2600
KH18 - Engine: Diesel S2200
KH151 - Engine: Diesel V1902BH
KX101 - Engine: Diesel V1902BH
KH60 - Engine: Diesel D1302
KH191 - Engine: Diesel S2800D
KH170L - Engine: Diesel S2600
Suitable for Carrier:
Transicold Kubota V2203-TV - Engine: Diesel CT4-134
Phoenix R22 (1995–Onward) - Engine: Diesel CT4
Phoenix NDM-94A (1995–Onward) - Engine: Diesel CT4
Phoenix NDA-94A (1995–Onward) - Engine: Diesel CT4
Genesis TR1000NDD (1995–Onward) - Engine: Diesel CT4
Generator UG15 (1995–Onward) - Engine: Diesel CT4
Extra NDM-94E (1996–Onward) - Engine: Diesel CT4
Package Includes:
1 x Starter Motor
🔧 Compatible Vehicles
| Make |
Model |
Years |
Engine |
| Kubota |
L295DT |
1977-1992 |
D1301A, V170DIA, V1500, D130DI, D1100, D1101, D110 |
